EcoMATE™ Fuel Consumption

Fuel consumption solution for seagoing vessels

  • Continuous measurement and reporting of fuel consumption on board ships
  • High accuracy flow readings from OPTIMASS Coriolis mass flowmeters
  • Benchmarking and comparison of performance
  • Fulfils the upcoming requirements from IMO and other authorities

View on the ship's bridge of a gas carrier ship

EcoMATE™, the electronic fuel management system (EFMS) from KROHNE, was specifically designed for real time monitoring of fuel consumption and bunkering. It has become the solution of choice for many major shipping companies. Regardless of the vessel type, once implemented, EcoMATE™ provides the whole picture you need to gain full knowledge and control of fuel consumption, emissions and bunkering transactions.

EcoMATE™ is a remote, cloud-based solution that can be accessed onshore. A basic set-up will consist of flowmeters mounted in the fuel supply and return lines, and in the bunkering line, plus the EcoMATE™ work station. Once implemented, the EcoMATE™ software takes care of data acquisition, logging, calculations, monitoring and reporting.

The EcoMATE™ Fuel Consumption Module, one of the four software modules within the EcoMATE™ family, monitors and stores detailed information about fuel usage, and generates the reports. Ideally coupled with high-performance OPTIMASS mass flowmeters in the supply and return lines to the main engine and each of the other consumers onboard, the combination gives the ideal solution for monitoring and reporting of total fuel consumption, plus reports for each separate consuming point. The EcoMATE™ system is designed to fulfil the proposed requirements from IMO and other authorities.

Highlights

  • Enables ship-owners to monitor all types of vessel with a single integrated tool
  • Provides detailed reports about the fuel consumption of both the main and the auxiliary engines (LNG, MGO, oil mixtures etc.)
  • Accommodates both manual and online measured data entry to record operational data for each voyage
  • Conducts data quality checks  and validations
  • Configurable model with various separately reported fuel consumers
  • Collects data from external systems
  • Creates voyage records with events logged
  • Logging of historical data
  • Full data integrity
  • Automatically interfaced with a cloud solution accessible by onshore personnel

Typical applications

Marine industry

  • Fuel performance monitoring and reporting for main engine and other consumers onboard
  • For all types of vessel

Case studies

Related products

OPTIMASS 6400 F Stainless steel version

OPTIMASS 6400
Marine version

Coriolis mass flowmeter for advanced ship fuel applications in the marine industry

OPTIMASS 1400 F Stainless steel version

OPTIMASS 1400
Marine version

Coriolis mass flowmeter for general ship fuel applications in the marine industry

P-105

Pressure transmitter for cargo level monitoring on ships

  • Precise absolute pressure measurement (up to 5.5 bar / 80 psi) with integrated temperature measurement
  • Chemically resistant Inconel housing material
  • Flush diaphragm: not affected by sludge or sediments
  • Holds marine approvals of all major classification societies
View product details

P-130

Pressure transmitter for tank level monitoring of liquids on ships

  • Precise absolute pressure measurement (up to 5.5 bar / 80 psi)
  • Robust stainless steel or Gr.II titanium design with PUR sealing for excellent resistance to corrosive warm ballast water
  • Semi flush ceramic diaphragm, not affected by sludge or sediments
  • DNV GL marine approval
View product details

P-140

Pressure transmitter for cargo lines, manifolds and pump pressure on ships

  • Precise absolute pressure measurement for cargo operations (up to 27.5 bar / 400 psi)
  • Robust stainless steel design with ceramic diaphragm for deck mounting (IP68)
  • Semi flush diaphragm design for easy maintenance
  • DNV marine approval
View product details

Related solutions

EcoMATE™ Bunker verification

Bunker verification solution for seagoing vessels

  • For verification of bunker fuel quantities received through the bunkering line
  • Enables data acquisition and logging, calculation and monitoring of bunkering operations
  • Utilises the high accuracy mass flow measurement available from OPTIMASS bunker meters
  • Allows checking of the fuel supplier delivery notes and the fuel oil costs billed
View solution details

EcoMATE™ MRV & IMO DCS Emission monitoring

Emission monitoring solution for seagoing vessels

  • For carbon emission monitoring, calculation and reporting
  • Certified according to EU regulation 2015/757 and MARPOL ANNEX VI
  • Provides accurate data for increased efficiency and reduced emissions (e.g. CO2)
View solution details

EcoMATE™ Cloud

Web reporting solution for seagoing vessels

  • Centralised web reporting tool for vessels running the EcoMATE™ system
  • Automatic transmission of data to shore for fleet reporting and monitoring
  • Safe access to actual measured data from vessels
  • Easy download and analysis of fleet reporting and monitoring data
View solution details
